Home » Machines » Jet grouting Jet grouting Hydraulic drill rig Casagrande C-4 Hydraulic drill rig C-4 is made under newest ecological standards and is used for jet grouting piling, anchoring, geomechanical research, smaller wells... Engine type Diesel Noise [dB] Max. slope inclination in transport mode [%] Max. slope inclination in work mode [%] Geomechanical drilling Jet grouting Anchoring Mini piling Diameters [mm] Vsi profiles One and two phase 143 - 153 150 - 250 Max depth [m] 25 12 25 25 Transport dimensions [cm][WxLxH] 180x500x253 180x500x253 180x500x253 180x500x253 Weight[kg] 7900 8200 7900 7900 Working dimensions [cm][WxLxH] 180x559x500-1120 180x559x500-1120 180x559x500 180x559x500-1120 Drill rig Casagrande C-6 Drill rig C-6 is used ofr jet grouting piling, geotechnical and IBO anchoring, geomechanical drilling, smaller wells... Engine type Diesel Hydraulic Noise [Db] Max. slope inclination in transport mode [%] Max. slope inclination in work mode [%] Drilling Jet grouting Diameters [mm] 50 - 305 - Max depth [m] 35 34 Transport dimensions [cm][WxLxH] 225x771x277 300x1700x365 Weight[kg] 13500 70000 Working dimensions [cm][WxLxH] 225x650x7,02 225x650x702 + (300, 500, 600 - extensions) Hidravlični vrtalni stroj Casagrande C-7 Hidravlični vrtalni stroj C-7 izdelan po najnovejših ekoloških normah in delo podprto z natančno računalniško spremljavo in obdelavo podatkov uporabljamo za izdelavo jet grouting pilotov, mini pilotov, geotehničnih in IBO sider, geomehanskih vrtin, manjših vodnjakov... Tip motorja Diesel Glasnost stroja [Db] Max. naklon brežine v transportnem položaju [%] Max. naklon brežine v delovnem položaju [%] Geomehansko vrtanje Jet grouting Sidranje Mini pilotiranje Premeri [mm] 50 - 305 - 143 - 153 150 - 500 Max globina [m] 35 34 18 Transportne dimenzije [cm][ŠxDxV] 250x1300x310 250x1300x310 250x1300x310 250x1300x310 Teža[kg] 22500 23000 22500 22500 Delovne dimenzije [cm][ŠxDxV] 250x870x1344 250x870x1344-1844 250x870x1344 250x870x1344 Hidravlični vrtalni stroj Casagrande C-8 Hidravlični vrtalni stroj C-8 izdelan po najnovejših ekoloških normah in delo podprto z natančno računalniško spremljavo in obdelavo podatkov uporabljamo za izdelavo jet grouting pilotov, mini pilotov, geotehničnih in IBO sider, geomehanskih vrtin, manjših vodnjakov... Tip motorja Diesel Glasnost stroja [Db] Max. naklon brežine v transportnem položaju [%] Max. naklon brežine v delovnem položaju [%] Geomehansko vrtanje Jet grouting Sidranje Mini pilotiranje Premeri [mm] Vsi profili eno in dvofazni 143 - 153 150 - 400 Max globina [m] 40 20 40 20 Transportne dimenzije [cm][ŠxDxV] 250x1130x340 250x1130x340 250x1130x340 250x1130x340 Teža[kg] 25700 26000 25700 25700 Delovne dimenzije [cm][ŠxDxV] 250x698x1130 250x698x1130-2130 250x698x1130 250x698x1130 Hydraulic drill rig Casagrande C-14 Hydraulic drill rig C-14 is made under newest ecological standards and is used for jet grouting piles, mini piles, geotechnical anchors, geomechanical researching, wells.... Engine type Diesel Power [kW] 190 Max. slope inclination in transport mode [%] 58 Max. slope inclination in work mode [%] 5 Max. torque [kN/m] 17,9 Geomechanical drilling Jet grouting Anchoring Mini piles Diameters [mm] Vsi profiles one and two phase 143 - 153 150 - 500 Max depth [m] 50 20 50 20 Transport dimensions [cm][WxLxH] 253x1110x300 253x1110x300 253x1110x300 253x1110x300 Weight[kg] 34000 34000 34000 34000 Working dimensions [cm][WxLxH] 409x850x1590 409x850x2090 409x850x1590 409x850x1590 Special hydraulic drill rig Boart Longyear DB 520 Special hydralic drill rig Boart Longyear DB520 is used for micro-piloing, geotechnical anchors, geomechanics, soil improvement with jet grouting technique an smaller wells. Speciality of this machine is drilling inside buildings because it's small and it's engine is seperated from the drilling part. Engine type Diesel Noise [dB] 75 Max. slope inclination in transport mode [%] Max. slope inclination in work mode [%] Geomechanic drilling Anchoring Mini piling Jet grouting Diameters [mm] All profiles 143 - 153 do 300 - Max depth [m] 15 15 15 15 Transport dimensions [cm][WxLxH] 115x700x205 115x700x205 115x700x205 115x700x205 Weight[kg] 3500+1400 3500+1400 3500+1400 3500+1400 Working dimensions [cm][WxLxH] 80/100x430x185- 355-700 80/100x430x185- 355 80/100x430x185- 355-700 80/100x430x185- 355-700 Visokotlačna črpalka P700 in mešalna postaja MIX20 Visokotlačna črpalka P700 in mešalna postaja MIX20 v sestavi s silosom za cement sta namenjeni za pripravo injekcijske mase pri izvedbi jet grouting pilotov. Silos za cement se uporabi pri porabi cementa večji od 20ton. Pri postavitvi silosa so potrebna zadosti trda tla (ali AB plošča). Kapaciteta mešalne postaje 20 Priključna električna moč [V] 280 Teža mešalne postaje[kg] 5500 Dimenzije mešalne postaje[cm] 600x250x250 Dimenzije črpalke 600x244x258 Teža črpalke [kg] 14000 Tip motorja Diesel Moč motorja [kW] 448 Max pritisk črpalke [bar] 600 Naklon tal pri postavitvi [%] 0
